Корпусной подшипниковый узел |
Диаметр вала |
Размеры,мм |
Болт |
Корпус подшипника |
Вес |
||||||||||||||
|
В сборе с В type |
В сборе с |
|
|
|
|
|
|
|
|
|
|
n |
|
|
|
RPW |
KHPW |
||
|
mm |
n |
a |
e |
b |
S1 |
S2 |
g |
w |
Bi |
L |
BPW |
KHPW |
w |
|
|
|
|
||
|
BPW 201 |
KHPW 201 |
12 |
30.2 |
114 |
87 |
25 |
11 |
16 |
7 |
55 |
22 |
28.6 |
6 |
6.5 |
28.6 |
M10 |
PW203K |
0.27 |
0.31 |
|
BPW 202 |
KHPW 202 |
15 |
30.2 |
114 |
87 |
25 |
1 1 |
16 |
7 |
55 |
22 |
28.6 |
6 |
6.5 |
28.6 |
M10 |
PW203K |
0.26 |
0.30 |
|
BPW 203 |
KHPW 203 |
17 |
30.2 |
114 |
87 |
25 |
11 |
16 |
7 |
55 |
22 |
28.6 |
6 |
6.5 |
23.6 |
M10 |
PW203K |
0 24 |
0 29 |
|
BPW 204 |
khpw 204 |
20 |
33 3 |
125 |
97 |
27 |
11 |
16 |
8 |
62 |
24.7 |
31 |
7 |
7.5 |
33.3 |
M10 |
PW204K |
0 37 |
0.37 |
|
BPW 205 |
KHPW 205 |
25 |
36.5 |
130 |
100 |
29 |
11 |
16 |
9 |
69 |
27 |
31 |
7.5 |
7.5 |
38.1 |
M10 |
PW205K |
0.46 |
0.48 |
|
BPW 206 |
khpw 206 |
30 |
42.9 |
156 |
120 |
33 |
14 |
21 |
10 |
81 |
30.3 |
35.7 |
8 |
9 |
44.5 |
M12 |
PW206K |
0.75 |
0.81 |
|
BPW 207 |
khpw 207 |
35 |
47.6 |
165 |
127 |
35 |
14 |
21 |
10 |
91 |
32.9 |
38.9 |
8.5 |
9.5 |
55.6 |
M12 |
PW207K |
0.98 |
1.1 |
|
|
KHPW 208 |
40 |
50.8 |
181 |
140 |
37 |
14 |
22 |
11 |
99 |
|
43.7 |
|
11 |
60.3 |
M12 |
PW208K |
|
1.4 |
|
|
KHPW 209 |
45 |
54 |
190 |
146 |
38 |
14 |
24 |
12 |
106 |
|
43.7 |
|
11 |
63.5 |
M12 |
PW209K |
|
1.5 |
|
|
khpw 210 |
50 |
57.2 |
202 |
157 |
40 |
14 |
24 |
13 |
112 |
|
43.7 |
|
11 |
69.9 |
M12 |
PW210K |
|
1.7 |
